Kinetico Essential Series Installation Guide

4
Typical Installation Overview
Kinetico recommends that you install your system in the following order:
A. System Set-up
B. Connect Plumbing
C. System Start-up
Note: This is a typical Essential installation configuration. Your installation may vary.
Fit a pressure regulating valve and non-return valve, if required, on the water
supply to the softener.
Figure 1
Untreated Water
Raw Water
Soft Water
to Home
Drain
Line
Overflow
Line
Installation with Three (3) Valve By-pass
Installation with Optional By-pass
Untreated Water
Raw Water
Soft Water
to Home
Drain
Line
Overflow
Line
Provide an air gap for all
drain lines. See page 6
for further information.

Kinetico Essential Series Specifications

General

Brand	Kinetico
Model	Essential Series
Category	Water Dispenser
Language	English
