King Technology Pool Frog - Off-line Installation (Models 5430;5630); Off-line Installation Guidelines; Connecting Adapters and Bushings; Attaching Elbows and Tubing

PVC
CEMENT
P
I
P
E
T
H
R
E
A
D
S
E
A
L
A
N
T
4
0
0
S
E
R
I
E
S
W
a
t
e
r
C
Y
C
L
E
R
M
e
t
e
r
e
d
P
o
o
l
P
u
r
i
f
i
e
r
PVC
CEMENT
P
I
P
E
T
H
R
E
A
D
S
E
A
L
A
N
T
Off-line Installation – Models 5430/5630
Two
Scoops
1. 2. 3.
4. 5.
6.
MATERIALS NEEDED:
#10 X 1 1/4" Phillips Pan
Head Screws with
Washers
PVC
Cement
Pipe Thread
Sealant
Check Valve
Rainbow #172288
RECOMMENDED:
Two
90 Degree Elbows
Two Male
Adapters
Two Reducer
Bushings
Four Hose
Clamps
OFF-LINE KIT
6' of Tubing
Two Scoop
Gaskets
Two Scoop
Clamps
Included with Cycler
Can be installed with the water flow in either
direction due to its bi-flow valve.
TOOLS NEEDED
Wrench
Battery
Operated Drill
with 5/8" or 19/32" Bit
Following pipe thread
sealant directions, brush
sealant on to elbow threads.
Following pipe thread
sealant directions, brush
sealant on to Cycler threads
in both ports.
Brush sealant on threads of
both male adapters.
DO NOT USE TEFLON TAPE
as the threads on these units
are not suitable for
this use and
leaking or bushing
failure could result.
Screw a male
adapter into each
port of Cycler
and hand tighten.
Completely
tighten
turning 1 to 2
revolutions
with a wrench.
DO NOT OVER TIGHTEN.
Following PVC cement
directions, brush PVC
cement on reducer
bushings and inside of
male adapters.
Insert reducer bushing
into male adapter on both
sides. Hold in place 5 to 10
seconds to bond.
Screwdriver
Do NOT install an off-line
Cycler in-line as this Cycler
is different than an in-line
unit.
Install off-line when insufficient room
for an in-line application. Install as far
from heater as possible.
P
I
P
E
T
H
R
E
A
D
S
E
A
L
A
N
T
D
e
l
i
v
e
r
y
S
Y
S
T
E
M
P
I
P
E
T
H
R
E
A
D
S
E
A
L
A
N
T
17
