indicator shows normal, please check oil filter A and replace it if
And when there is no oil or very little oil comes out of nozzle even
Although the machine is using oil pump lubrication and Splashing
器(A)，清掃乾淨或更新。
正常，而循環視窗發現油量減少或是不出油，請立即檢視過濾
本機器採用強制過濾潤滑系統，長期使用後，雖然油面計指標
5-4. 潤滑油過濾器 Oil filter
lubrication systems, please check and clean oil Filter every month.
線冷卻裝置。冷卻油以矽油的效果最好，在某些情況下不必
5-5. 添加冷卻油 Adding cooling oil
高速縫製時，磨擦發熱使得作業上產生許多困擾，例如斷針，
跳線，熔解等問題，因此本機器上裝設有針尖冷卻裝置及針
Avoid needle breaking, stitch jumping or thread melting problems
etc. Please fill cooling oil tank and felt B with silicone oil under
some special circumstances. You can take felt B off from reservoir.
使用冷卻油或不能使用冷卻油時，可將羊毛氈(B)取出。
6.針 Needle
6-1. 針號選擇 Needle selection
本機型全系列使用針號為 UY128GAS 依照裁片的厚度，縫線的粗細等選用適當的針號。
Needle UY128GAS of schmetz or organ is to be used there are many sizes of needle, and the most suited needle to
the thickness and the kind of material should be selected.
西德編號 Metric size
日本編號 Japanese size 9 10 11 12 13 14
908580757065
針在安裝的時候必須朝向正確的方向，也就是針窩必須朝向正後方，並且向上定位。
6-2. 正確的安裝針 How to replace the needles
When replacing needle should be made correctly with the scarf facing rightly backward as shown in the illustration,
When you can not use or do not need to use silicone oil.
and at its uppest dead point.
necessary.
A
B
