KT SERIES PART NUMBER DESIGNATIONS
EXAMPLE: MODEL KT300D-M4A0
POSITION #:
1 2 3 4 5 6 7 8 9 10 11
K T 3 0 0 D – M 4 A 0
POSITIONS 1–5:
PUMP MODEL NUMBER
POSITION 6:
PUMP REVISION LEVEL
POSITION 8:
SCOPE OF SUPPLY
L = Pump Complete Less Motor
M = Pump Complete
POSITION 9:
ENCLOSURE RATING
4 = NEMA 4
7 = NEMA 7
POSITION 10:
POWER SUPPLY OPTIONS
VOLTAGE TEFC XP
3/60/200 9 G
3/60/230-460 A H
3/50/190-380 D L
3/60/575 E M
POSITION 11:
SERVICE OPTIONS
0 Standard Construction Viton
2 Phosphate (TAP) Viton
3 Refrigeration (POE) Buna
4 Mineral Oil Buna
5 Hardened Internals (QPQ)
6 Brake Fluid (UCON) EPR/EPDM
7 Ammonia Service (POE) EPR; no Cu/Bronze
8 Customer Supplied Oil (O2)
9 Radiator Filled Buna
