PUMP PARTS LIST – KT-150, KT-300, KT-500, KT-850
ITEM NO. PART DESCRIPTION
QTY
KT-150 KT-300 KT-500 KT-850
1 Pump 1 1 1 1
2 Motor 1 1 1 1
3 Belt Guard 1 1 1 1
4 Motor Sheave 1 1 1 1
5 QD Bushing 1 1 1 1
6 Pump Sheave 1 1 1 1
7 QD Bushing 1 1 1 1
8 V-Belt 1 1 1 1
9 Spacer 1 – 1 1
10 Belt Guard Standoff 3 4 4 5
11A Vibration Mounts 4 4 4 1
11B Vibration Mounts – – – 1
11C Vibration Mounts – – – 2
12 Stud for Vibration Mount 4 4 4 4
13 Motor Rod End 2 2 2 2
14 Hex Nut 2 2 2 2
15 Washer 6 6 4 4
16 Hex Head Cap Screw 2 2 2 2
17 Rod End, S. Housing/Block 2 2 2 –
18 Jam Nut/Screw 2 2 4 –
19 Hinge Pin 1 1 1 1
20
Retaining Ring 2 2 2 2
21 Plate 1 1 1 0
22 Jack Screw 1 1 1 1
23 Jam Nut/Screw 2 2 2 2
24 Lock Washer Reg. Spring 1 1 1 1
25 Hex Nut 1 1 1 1
26 Snap Plug, Rotation View 1 1 1 1
27 Truss HD Screw 3 4 4 5
28 Hex Nut 2 2 2 –
29 Spacer – – – 2
30 Pillow Block – – – 2
31 SHCS 1/2-13-2 – – – 4
32 Belt Guard Standoff
–
4
– –
33 Truss HD Screw
–
4 4
–
