Parts Lists and Assembly Drawings
Manual 1843 Rev C p/n 001843 0000
PUMP PARTS LIST – KT-150C, KT-300D, KT-500D, KT-850D
ITEM NO. PART DESCRIPTION
QTY
KT-150C KT-300D KT-500D KT-850D
1 Cylinder Head 1 1 1 1
2 Head, Open End 1 1 1 1
3 Head, Closed End 1 1 1 1
4 Housing, Oil Pump 1 1 1 1
5 Housing, Bearing and Shaft Seal 1 1 1 1
6 Separator Housing 1 1 1 1
7 Cover, Separator Housing 1 1 1 1
8 Valve Deck Cover 1 1 1 1
9 Top Plate 1 1 1 1
10 Bottom Plate 1 1 1 1
11 Cam, Center 1 1 1 1
12 Piston, Center 1 1 1 1
13 Slide Pin, Center 1 1 1 1
14 Cam, Outer 2 2 2 2
15 Piston, Outer 2 2 2 2
16 Slide Pin, Outer 2 2 2 2
17 Removable Wall 1 1 1 1
18 Shaft Replacement Assembly 1 1 1 1
19 Shaft Seal Head Assembly 1 1 1 1
20 Shaft Seal Seat 1 1 1 1
21 Drive Coupling – 1 1 1
22
Ball Bearing 1 1 1 1
23 Bearing Locknut 1 1 1 1
24 Discharge Valve Assembly 4 7 8 12
25 Valve Hold-down Plate 4 2 4 4
26 Sleeve Bearing, Heads 2 2 2 2
27 Retaining Ring, Cam 1 1 1 1
28 Sight Glass 1 1 1 1
29 Clamping Ring, Sight Glass 1 1 1 1
30 Gasket, Sight Glass 1 1 1 1
31 Discharge Baffle Assembly 1 1 1 1
32 Bushing 1 1 1 1
33 Key, Drive 1 1 1 1
34 Key, Woodruff 6 6 6 6
35 Oil Pump 1 1 1 1
36 Pin, Wall Locking 3 3 5 5
37 Setscrew, Wall Locking 3 3 5 5
38 Setscrew – 1 1 1
