KINNEY KT300 - Page 46

40
Parts Lists and Assembly Drawings
Manual 1843 Rev C p/n 001843 0000
ITEM NO. PART DESCRIPTION
QTY
KT-150C KT-300D KT-500D KT-850D
39 Gasket, Cylinder/Separator Housing 1 1 1 1
40 Gasket, Separator Housing Cover 1 1 1 1
41 Gasket, Top Plate* 1 1 1 1
42 Gasket, Bottom Plate – 1 1 2
43 O-Ring, Housing 2 2 2 1
44 O-Ring, Oil Pump 1 1 1 –
45 Pipe Plug, Square Head 2 1 2 2
46 Pipe Plug, Hex Socket 2 3 3 2
47 Eyebolt 2 2 2 1
48 Nipple 1 1 1 1
49 Elbow – – 1 –
50 Male Connector 1 – 1 1
51 Bushing 1 – 1 1
52 Bushing – 1 1 1
53 Pipe Plug, Hex Socket 4 1 2 2
54 Strainer – – 1 1
55 Discharge Valve Assembly – – 1 1
56 Te e 1 1 1 1
57 Bushing 1 1 2 2
58 Press, Gauge, 0-160 PSI 1 1 1 1
59 Nipple 1 1 1 1
60
Check, Valve Spring 1 1 1 1
61 Male Elbow – 2 1 1
62 Female Elbow 1 1 1 1
63 Nipple – – 1 1
64 Ball Valve 1 2 2 2
65 Check Valve, Swing 1 1 1 1
66 Angle Valve, G.B., 1/8 NPT 1 1 1 1
67 Relief Valve 1 1 1 1
68 Pipe Plug 2 1 1 1
69 Male Connector, Gas B. 1 1 4 4
70 U-Tube, Gas B. – – 2 2
71 ST Elbow 1 2 2 2
72 Bushing – 1 1 1
73 Pipe Plug 1 1 2 2
74 Plate, Bearing Retainer – 1 1 1
75 Socket Head Cap Screw – – 4 4
76 Nipple 1 1 4 4
77 Hex Head Cap Screw 36 20 33 44
78 Hex Head Cap Screw 4 34 12 16
