41
Parts Lists and Assembly Drawings
Manual 1843 Rev C p/n 001843 0000
ITEM NO. PART DESCRIPTION
QTY
KT-150C KT-300D KT-500D KT-850D
79 Hex Head Cap Screw 16 18 28 30
80 Hex Head Cap Screw 30 16 32 32
81 Hex Head Cap Screw 28 14 4 18
82 Hex Head Cap Screw 6 6 6 6
83 Socket Head Cap Screw 4 6 6 6
84 Socket Head Cap Screw 12 21 24 24
85 Dowel Pin 4 4 4 4
86 Pipe Plug, Hex Socket 1 2 1 1
87 Pipe Plug, Square Head 3 5 5 2
88 Steel Tubing – 36 24 12
89 Steel Tubing 24 21 24 36
90 Hex Head Cap Screw 2 – 4 4
91 Spacer, Slide Pin 2 2 2 2
92 Pipe Plug, Hex Socket – 3 3 1
93 Gasket, Oil Baffl – – 1 1
94 Te e 1 1 1 1
95 Hex Head Cap Screw 12 – 6 6
96 Mesh Pad – – 1 1
97 Male Elbow 1 – 1 1
98 ST Elbow 1 – 1 1
99 Temperature Gauge 1 1 1 1
100
Pipe Plug, Hex Socket 2 2 2 2
101 Ring, Shaft Seal Backup 1 1 – 1
102 Nipple – – – 1
103 Female Elbow – – – 1
104 Bushing – – – 1
105 Dowel Pin – – – 4
106 Pipe Plug, Hex Socket – – – 2
107 Ring, Bearing Backup 1 1 – –
108 Hex Head Cap Screw 2 – – –
109 Lock Washer Reg. Spring 2 – – –
110 Plate 1 – – –
111 Bushing 1 – – –
112 Key, Woodruff – – – 1
113 Hex Head Cap Screw – – – 4
114 Hex Head Cap Screw – 10 – –
OTE: N * Not shown.
