Technical Data
Issue: 04/2011

 
 
 
 
Name Console Film Projector
Type FP 50 D
Machine No. See data plate on housing.

Power supply 120/208 V 3 ph, 5 wire -OR-
230/380 V, 5 wire V
Frequency 50 Hz / 60 Hz
External required over-current protection
for 3 x 208 V
30 A (depends on rectier type)
External required over-current protection
for 3 x 380 V
20 A (depends on rectier type)
Power max. depends on equipment, see data
plate

Nominal rotary frequency of main drive motor 1500 rpm
Power of main drive motor 100 W

  
Projector 1500 mm x 714 mm x 2240 mm approx. 300 kg
Film spools 600 m / 1800 m / 2000 m
Friction shafts Ø 9 mm or Ø 12.7 mm or 5/16”
Apertures 1:1.37 / 1:1.66 / 1:2.35
