2. Disconnect the connector and loo-
sen the nut from the bottom of the
fender to remove the turn signal
lamp assembly.
(1) Connector (2) Nut
td2O742A
3.
Loosen the screw to remove the cover.
td2O741A
(1) Screw (2) Cover
td2O743A
(1) Turn Signal Lamp (2) Position Lamp
4. Turn the socket counterclockwise
to remove the bulb and replace it
with a new one.
To Next Page
