LX500L
The parts suitable for the coupler
and hydraulic hose can be sup-
plied by the KIOTI Dealer.
•
NOTE
CONNECTING AND DISCONNECTING THE DOUBLE ACTING VALVE COUPLER
CONNECTION
1. Clean the two couplers thoroughly.
2. Remove the protective plug.
3. Engage the implement coupler to
the hydraulic coupler of the tractor.
4. Pull the implement coupler slightly
to check that the coupler is engaged
tightly.
REMOVAL
1. First, lower the implement to the
ground to remove the hydraulic in
the hose.
2. Clean the coupler thoroughly.
3. Stop the engine and move the hy-
draulic control lever to release the
pressure. Pull the hose out straight
to decrease the hydraulic pressure
from the hydraulic coupler.
4. Remove oil and dust from the cou-
pler and install the protective plug.
To avoid personal injury:
Stop the engine and release the
pressure before you connect or
disconnect the line.
Do not use a hand to check for
any oil leakage.
•
•
CAUTION
