KIP 7900 - Page 31

Chapter 2 Basic Operations 2-8
5. Push both the levers (4) down in either way. Position them flat against Flange to secure the roll
media.
6. Lift the roll media by holding both Flanges. Lower Flanges onto Slide Guides (5).
(Continued on the next page)
4 4
5
