Kipor IG6000 Service Manual

2
1．SPECIFICATIONS and DIAGRAMS
1.1 General Specifications
Dimensions and weights
Model
IG6000
Overall length- in. (mm)
31.6 (802)
Overall width- in. (mm)
19.4 (498)
Overall height- in. (mm)
24.6 (624)
Dry weight- lbs. (Kg)
213 (96.7)
Engine
Model
KG390GETi
Type
4-stroke,OHV, single cylinder
Displacement- cu.in. (cc)
23.7 (389)
Bore x stroke- in. (mm)
3.46 x 2.51 (88×64)
Maximum horsepower(KVA)
7.7/3600
Compression ratio
8.5:1
Cooling system
Forced air
Ignition system
Transistorized controlled ignition
Ignition timing
25°B.T.D.C
Spark plug
WR7DC
Carburetor
Horizontal float & fly type
Air cleaner
Dry replaceable element
Governor
Inverter module control
Lubrication system
Forced splash
Oil capacity- qt. (L)
1.2 (1.1)
Starting system
Electric starter
Stopping system
Electric ground
Fuel
Automotive unleaded gasoline
Generator
Model
KD70
Generator type Multi pole rotation type
Generator structure Self-ventilation drip-proof type
Excitation Self-excitation (Magnet type)
Voltage regulation system Pulse Width Modulation
Phase Single phase
Rotating direction
Clockwise (Viewed from the generator)
Frequency regulation
AC-DC-AC conversion (Inverter type)
