Kipor IG6000 Service Manual

3
1.2 Generator Specifications
Model
IG6000
Maximum output
（
AC
）
6.0 KVA
Rated output (AC)
5.5 KVA
Rated frequency (HZ) 60
Rated voltage（AC）
120/240
Maximum current (amp) 50/25
Rated current（amp）
45.8/22.9
Rated voltage（DC）
12V
Rated current（DC）
5A
Power factor
1.0
Voltage variation
rate
Momentary
Max.10%
Average
Max.1.5%
Average time
Max. 3 seconds
Voltage stability
±1%
Frequency
variation rate
Momentary Max. 1%
Average Max. 1%
Average time Max. 1second
Frequency stability ±0.1%
Insulation resistance Min. 10MΩ
AC circuit protector- Amps 120/240 VAC
51.7/25.8
DC circuit protector
7A
Fuel tank capacity- gal (L)
5.4 (20)
Operating hours at rated load
5.5
Noise level dB @23’ (7 m) no load-full load 65-75

Kipor IG6000 Specifications

General

Brand	Kipor
Model	IG6000
Category	Inverter
Language	English
