9. Major Specifications
Model
Frequency
Tx clusters and harmonics
PT3600
136-174MHz VHF
400-470MHz UHF
4W(UHF) 5W(VHF)
<-70dB
RF power
Frequency stability ±5ppm
Max. deviation ±5KHz(W)/ ±2.5KHz(N)
Rx sensitivity ≤0.18μV
Channel selectivity >60dB
Intermodulation >60dB
Max. audio power ≥1000mW
Channel number 16(15+S)
Power supply DC 7.4V
External dimension 47mm×107mm×33mm
Weight
225g
(with battery and antenna)
10. Status Setting (by the dealer)
Model: Serial No.:
1. Channel setting
Channel No. Tx frequency Rx frequency CTCSS/DCS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
A.Make sure the antenna is well connected.
B.Make sure the antenna is the original supplied one.
C.Check if the battery power is in normal state.
D.Ask your local dealer to adjust the squelch level.
Causes and Solutions
Problem
The communication range is
too short.
No.
5
