INSTALLATION
INSTALLATION
Position the cords.
From the outside of the end plate, place the washer on the end of one cord behind the slot in the middle of the end plate, so
that the cord fits into the slot. Pull the cord taut to seat the washer.
Cut the knot from the end of the other cord and tie the cord to the cord tensioner using a square knot. (There are two cord
tensioners in the headrail; one is a spare.) Trim the end of the cord to about
1
⁄
2
".
Loop the cord from the tensioner around the “T” near the front of the end plate. The top of the loop must be the cord from
the cord tensioner. Be sure the cord is not twisted.
Remove slack from the cord by moving the cord tensioner away from the end plate it is looped around.
If the tensioner must be moved more than one-third of the headrail width away from its end plate to remove slack, re-tie the
knot and trim the excess cord.
Do not put tension on the cord at this time. Just remove the slack.
Washer
Slot
Top from
Tensioner
Bottom from
Moving Rail
Loop Around
the “T”
To Next Page
