INSTALLATION
VALANCE INSTALLATION
Attach dovetail brackets to the valance clips.
Insert the top of the dovetail bracket into
the top of the valance clip.
Rotate the dovetail bracket down to snap it
in place.
Attach the valance to the dovetail brackets, as shown below.
Place the top groove of the valance into the top of the dovetail bracket.
Rotate the valance down and squeeze the dovetail bracket against the valance to snap it in place.
Room Divider Installation
If you ordered a room divider kit, you received a second valance along with the appropriate number of rear valance clips.
Installation of the shade is the same as an inside mount. The only additional step is attaching the second valance to the rear side of
the headrail.
Attach the rear valance clips to the rear of the headrail, as shown below.
Attach the rear valance the same way you attached the front valance.
Inside Mount
Headrail
Dovetail
Bracket
Valance
Squeeze
Outside Mount
Headrail
To Next Page
