GETTING STARTED
Thank you for purchasing the Kirsch
®
Cellular Shade Collection. With proper installation, operation, and care, your new shades will
provide years of beauty and performance.
Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation.
Tools and Fasteners Needed
■
1
⁄ 4 " Hex, Flat Blade and Phillips Screwdrivers
■
Level (laser level is recommended)
■
Measuring tape and pencil
■
Power drill,
3
⁄ 32 " drill bit, and
1
⁄ 4 " hex driver
In addition, you will need fasteners designed to work with your specific mounting surface(s).
■
#6 Hex Head Screws (Provided). Two 1
1
⁄ 2 " screws are provided per installation bracket.
■
Longer #6 Hex Head Screws (Not Provided). If using spacer blocks, use #6 screws long enough for a secure attachment.
■
#6 Flat Head Screws (Provided). If end mounting the shade, use two 1
1
⁄ 2 " screws per installation bracket.
■
Speed Nuts and Screws (Provided). Extension brackets come with speed nuts and screws.
■
Drywall Anchor (Not Provided). Use drywall anchors when mounting into drywall.
Speed Nut
and Screw
(Provided with Each
Extension Bracket)
#6 x 1
1
∕ 2 "
Hex Head Screw
(Provided)
Longer #6 Hex Head Screw
for Use with Spacer Blocks
(Not Provided)
#6 Flat Head Screw
for Use with End Mounts
(Provided)
