Parameter list PA2 (cold regulator)
Access: Set key switch 1 to position P, press buttons 3 and 8 simultaneously for 4 seconds, select PA2 using button 3, keep
button 12 pressed and set -7 (minus 7). Now button 3 or 8 can be used to scroll through the parameter list.
The value of the parameter selected is displayed when button 12 is pressed. It can be adjusted by pressing button 3 or button 8
in addition. The new value is stored immediately when button 12 is released.
The value is automatically reset to the original value if no key is pressed for 45 seconds or by simultaneously pressing buttons 3
and 8 for approx. 4 seconds.
Parameter
Functional description
Setting range
MED-288
C1
Reference value upon delivery
C7 ... C6
5.0 °C
C3
Switching sense
0: Heating contact
1: Cooling contact
1
C4
Hysteresis
0,1 ... 15.0 K
1.5 K
C5
Hysteresis mode
0: symmetrical
1: one-sided
1
C6
Upper reference value limit
C7 ... 999 °C
20.0 °C
C7
Lower reference value limit
-99 °C … C6
2.0 °C
C8
Start-up protection after compressor start
0 ... 240 min.
0 min.
C9
Start-up protection after compressor stop
0 ... 240 min.
3 min.
C10
Start-up protection for compressor after mains
supply switch-on
0 ... 240 min.
0 min.
C13
Switch-on period in the event of a sensor fault
(emergency operation)
0 ... 100 %
20 %
C14
Cycle time in the event of a sensor fault (emer-
gency operation)
5 ... 60 min.
10 min.
C15
Automatic defrost function
Superfrost
0: none
1: time-controlled
0
C16
Time limit for superfrost function
4 ... 36 hours
12 hours
F15
Fan mode cooling operation
1: Permanently on
2: As 1, with drip interruption
3: With compressor on
4: Temperature controlled
2
F16
Fan control cooling operation
1: Evaporator sensor only
2: Difference cold store - evaporator
2
F17
Fan mode defrosting
0: off
1: on
1
F18
Delay after compressor on
0 ... 240 min.
0 min.
F19
Delay after defrosting
0 ... 240 min.
0 min.
F20
Dripping interruption time (for F15=2)
0 ... 240 min.
5 min.
F21
Control offset (for F15=4)
0 ... 15.0 K
0 K
F22
Hysteresis (for F15=4)
0,1 ... 15.0 K
0.5 K
d1
Defrosting interval
0: no automatic defrosting
1 ... 99 hours
12 hours
d2
Type of defrosting
0: No defrosting
1: Only compressor off
2: Electric
3: Hot gas
1
d3
Stop at defrosting temperature
0 ... 30.0 °C
5.0 °C
d4
Defrosting time limit
1 ... 99 min.
90 min.
d7
Temperature difference for previous
cool-down
0 ... -15 °C
0 °C
d8
Maximum cooling time for previous
cool-down
0 ... 180 min.
0 min.
d9
Dripping time
0 ... 15 min.
0 min.
d10
Stop time drip dish heating
0 ... 60 min.
0 min.
