INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS
Mounting the
Enclosure For
The 75LC
Any enclosure used for 75LC mounting must provide multiple wire access hubs for running line voltage
wiring and low voltage wiring in separate conduits. Determine the wire access hubs to be utilized for
the installation and plug and seal any remaining unused openings with hardware and/or sealant. The
75LC will t into a typical outdoor, single gang outlet box.
Surface Mount: A typical outdoor, single gang outlet box may be used for surface mounting. Mount
the enclosure vertically onto the desired surface. If fastening the enclosure with screws directly
through the back wall of the enclosure, use two screws, centered vertically above and below the
opening in the rear of the enclosure.
Flush Mount: (See ush mount cutout template, pg 17). Make the cutout and the mounting holes
into the compartment door frame or compartment wall as shown on the cutout template. Once the
cutout and mounting holes have been made, screws in the mounting holes may be used to hold the
selected enclosure in place during the foaming process.
Mounting the IP-1
The IP-1 may be ush mounted into a standard J-Box. A typical outdoor type single gang outlet box
may be used for surface mounting. (NOTE: The IP-1 is a low voltage device. Wiring to the IP-1 must
not be installed in the same conduit as line voltage wiring. An 8’ length of color coded wiring for
connecting the IP-1 is provided.) Typical mounting location for the IP-1 is inside of the walk-in adjacent
to the door. Any wire pathways or other openings leading into the enclosure for the IP-1 from outside
of the walk-in must be sealed both on the outside and on the inside of the walkin to prevent a pathway
for condensation.
Mounting the MD-1
or MD-1+2
The MD-1 or MD-1+2 may be ush mounted into a standard J-Box. A typical outdoor type single
gang outlet box may be used for surface mounting. (NOTE: The MD-1 or MD-1+2 is a low voltage
device. Wiring to the MD-1 or MD-1+2 must not be installed in the same conduit as line voltage wiring.
A 6’ length of color coded installation wiring is pre-connected to the MD-1 or MD-1+2). Typical
mounting location for the MD-1 or MD-1+2 is inside of the walk-in above the door. There is no need
to open or access the motion detector itself. Mount the MD-1 or MD-1+2 horizontally with the white
oval lens facing down. The red light inside of the MD-1 or MD-1+2 will illuminate whenever the MD-1
or MD-1+2 is activated.
WIRING: See Wiring Diagrams, page 18. Keep wiring relatively short inside of the enclosure for the
75LC. Make sure that wiring openings into all enclosures are sealed properly to prevent a pathway
for condensation.
Line Voltage Wiring
on the 75LC
The line voltage terminal block will accept up to 12AWG wire. Wire the 3 line voltage connections in
accordance with the accompanying 75LC Connections diagram. Connections are also marked on
the 75LC.The stripped end of the line voltage wire connections should be kept short, approximately
¼” long. Insert the wire ends into the appropriate terminal block openings and tighten the screws
securely to clamp the wires into place. With stranded wire, make sure that all strands are captured
in the terminal block openings. Tug on wire to make sure connections are secure. MAKE SURE THE
SCREWS ARE TIGHT! Supply connection wiring must be rated at least 90°C. Use copper conductors
only. Make sure that the green wire from the 75LC faceplate is properly grounded. If a metal enclosure
is used for mounting the 75LC, make sure that the enclosure is also properly grounded.
