Kitchen Brains Modularm 75LC - FLUSH MOUNT CUTOUT TEMPLATE

MODULARM
®
75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 17 of 24
kitchenbrains.com
1-800-327-8766
3 1/4" 2 7/8"
2 1/2"
FLUSH MOUNT
CUTOUT TEMPLATE
1 5/8"
1 1/4"
FLUSH MOUNT CUTOUT TEMPLATE
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
1A@120VAC
C NC NO
SUPPLY
POWER
120 VAC
LIGHTS
8.3A@120VAC
1000W
NEUTRAL
LINE
LIGHTS
N/C
CONTACTS
TEMP.
PROBE
MD-1
MOTION
DECTECTOR
IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
IMPORTANT!!
MOUNT THE 75LC
ENCLOSURE WITH THE
GROUND LUG TO THE LEFT
SO THAT THE BATTERY
GROUND LUG WHEN THE
ALARM IS INSTALLED
GROUND
LUG TO
LEFT!!
75LC
ENCLOSURE
POSITION
DOES NOT CONTACT THE
(WHITE)*
(BLACK)*
(RED)*
*COLORS INDICATED ARE TYPICAL
75LC TERMINAL
BLOCK
LINE VOLTAGE CONNECTIONS
75LC CONNECTIONS
CONNECT THE GROUND WIRE
TO GROUND LUG BEFORE
INSERTING 75LC
