5. Built-up oors – add shims as needed
Note: The wood runners that come with the shipping base work
well for shims.
Built-up oors: If the kitchen oor is higher than the cabinet
opening’s oor - for example, the kitchen oor tile does not
extend into the cabinet opening - add shims, as needed, in the
area shown to bring cabinet oor up to same level as the kitchen
oor.
NOTE: Shims must be securely attached to oor to avoid
movement when the dishwasher is in use.
Cut insulation blanket along perforation for cabinet opening
height of 33½" (85.1 cm). For other cabinet opening heights, do
not cut the insulation blanket.
ELECTRICAL CONNECTION
– For Direct Wire, begin with Step 7
– For Power Cord, wait until Step 18
If installing with direct wire, route the cable as shown. Do not
connect the wire to the product at this time. This connection will
be made later, after the unit is installed into the cabinet opening.
Route cable from power supply through cabinet hole. (Cable
must extend to the right front side of cabinet opening.) Tape
cable to the oor in area shown. This will prohibit cable from
moving when dishwasher is moved into cabinet opening.
6. If installing into a 33½" (85.1 cm)
opening
6”
(15.2 cm)
7. Direct wire – route cable
Shim
To Next Page
