17
Copper tubing only: Put the tubing into the 90° elbow tting as
far as it will go. (The copper tubing bends and kinks easily.) Push
the nut and ferrule forward and tighten it, so that it sits right up
against elbow threads.
NOTE: To avoid vibration during operation, route the water
supply line so that it does not touch the dishwasher base, frame,
or motor. If using copper tubing, skip step 14 and go to 15.
14. Flexible line
Flexible braided line: Conrm the exible braided line is long
enough.
Get 3/8" compression x 3/4" hose tting with 90° elbow. Connect
the 3/8" compression tting of the 90° elbow tting to the water
supply line. Attach such that the 3/4" connection is facing
upward as shown above.
CONNECT FILL HOSE TO FILL VALVE
16. Tighten 90° elbow tting to valve
Elbow tting
Be sure rubber washer is properly seated in tting. Slide the
3/4" (19 mm) tting of the 90° elbow up to the valve and hand
tighten it to avoid cross-threading. Hand tighten until the coupling
is tight.
Using pliers, check the tightness of the coupling. An additional
1/4 to 1/2 turn may be required to seal the rubber gasket. Route
ll hose out the rear left side of unit.
NOTES:
■ Do not use tape with compression ttings.
■ Do not over-tighten. Damage to the coupling can result.
■ Route water supply line out rear of unit before setting unit up.
Nut
Ferrule
13. Slide nut and ferrule onto tubing
(copper tubing only)
15. Add 90° elbow tting to the water
supply line
