16
Measure the height of cabinet opening from the underside of the
countertop to the oor where the dishwasher will be installed.
Be sure to measure the lowest point on the underside of the
countertop and the highest point on the oor.
Use wrench to initially loosen leveling legs if needed.
Adjust all four leveling legs to the same height by rotating each
foot clockwise or counterclockwise as needed.
The unit comes with the legs set for a 33½" (85.1 cm) height
installation. If your opening height is 34½" (87.6 cm), you would
therefore need to lower all four legs by 1" (2.54 cm).
NOTE: Adjust rear leg height rst before moving unit into the cut
out.
Legs can be removed if necessary for tight installations.
CONNECT WATER LINE TO FILL VALVE
– For Copper line, begin with Step 12
– For Flexible line, begin with Step 14
If using copper tubing, measure overall length of copper tubing
required to reach the water supply, cut to length, and attach with
compression ttings.
11. Measure cabinet opening
Leveling leg adjustment
12. Copper Water Line
