8
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the recommended tools and parts before starting
installation. Read and follow the instructions provided with
thetools listed here.
All Installations
Tools Needed:
Pliers Flat-blade screwdriver
Phillips screwdriver Utility knife
5/16" (7.9 mm) and
1/4" (6.4 mm) nut drivers or hex
sockets
Small level
Measuring tape or ruler 5/8" (15.9 mm) open-end
wrench
10" adjustable wrench that
opens to 1
1
/
8
" (29 mm)
Torx
†
T20 and, if installing
custom front panels, Torx T15
screwdrivers
Other Useful Items You May Need:
Flashlight Shallow pan
Bath towel Masking, or duct tape
Parts Supplied:
Drain hose clamps (2)
(1 large/red and 1 small/silver)
Drain hose
#8 x 1/2" (12.7 mm) Phillips-head
screws (2)
Undercounter mounting
brackets (2)
Make sure all parts are included in the literature package.
Door handle (on some models)
†TORX, T15, and T20 are trademarks of Acument Intellectual Properties, LLC.
