CaseandGearingParts
Illus.No. PartNo.Descr Illus.No. PartNo.Descr.
1 GearcaseMotorHousing 18 9709231WormGear
(seecolorvariationpartspage)
 2 9703315CapAttachmentHub(Chrome)19 9706648ControlAssm.W/blackknob
 3 W10749681BlackTrimBand 21 3400200Screw
 4 9709125TransmissionHousing 22 3400617Screw
 5 9703338AttachmentHubGear 23 9709194BlackThumbScrew

6 9709511TransmissionGasket 24 9703312HallEffectSensor
 7 9703680RetainingClip  25 W10247536120VMotor
 8 9703337BevelGear  26 Powercord
W10164887White
W10325656Black
 9 9707223RetainingPin  28 PlanetaryAssembly(SeeColorVariation)
 10 9706529WormFollowerGear 29 W10323379FiberWasher
 11
LowerGearcase(SeeColorVariationPage)30 9703438RetainingRing
 12 16897LowerCenterBearing  31 9706090Washer
 13 9703339InternalGear  32 9707627PinionGear
 14 3400814Screw33 8533910Washer
 15 9706247MotorSealShaft 34 9708191AgitatorShaft
 16 Bearing   35 9704677GroovePin
W10170081Rear

W10170080Front





















