KitchenAid KF26M22 - Page 15

Original 1
st
Stage Gear
From: Start of Production Through: Date Code WL03
Rear Bearing-9703351(.193” Beyond Flange) 1
st
Stage Worm Assembly-9703699
Front Bearing-9703351(.193” Beyond Flange) Thrust Washer-9703677
Original Transmission Cover
Single Cavity/No Markings WK08-WL08
(Always inspect for cracks)
.86”
.193” Both Bearings
1pc Thrust Washer
53 Tooth Gear Either Stamped with a
T or Blank.
RibBehindBearingFlange .Not
compatiblewithRollerThrust
Bearing“Enhanced1
st
stageand
Bearing”
