4-6
g) Remove the end of the dispenser tube
from the bellows.
h) Use a 7mm socket, and turn the bel-
lows retainer clamp screw counter-
clockwise until the clamp is loose
enough to remove from around the
bellows.
Dispenser Tube
Bellows Retainer
Clamp Screw
i) Remove the bellows retainer clamp.
j) Remove the bellows from the front of
the tub.
Remove Bellows
Retainer Clamp
Remove Bellows
To Next Page
