4-7
REMOVING THE FLOWMETER
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
WARNING
1. Unplug washer or disconnect power.
2. Turn off the water supply to the washer.
Flowmeter
4. Loosen the two clamps and remove the
two hoses from the ends of the flowmeter.
5. Disconnect the wire connector from the
flowmeter.
3. Remove the top cover and the console
(see page 4-2 for the procedures).
Wire Connector
Flowmeter
To Next Page
