4-24
e) Disconnect the dispenser power con-
nector.
Wire Tie
Water Dispenser Fill Tube Nut
b) Place a container near the base grille to
catch the water in the next step.
c) Disconnect the water dispenser fill tube
from the union, slide the nut off the end
of the tube, and allow the water to drain
into the container.
d) Cut the wire tie around the bottom door
hinge.
f) Close the freezer door to hold it in
place.
g) Remove the three Torx screws from
the top hinge and remove the hinge.
h) Open the freezer door and lift it off the
bottom hinge.
Top Hinge
Torx Screw
(1 of 3)
Dispenser
Power Connector
To Next Page
