7-2
STRIP CIRCUITS
THE COOLING CIRCUITS
The Compressor
Electronic
Control Board
Thermistor
Compressor
Inverter
Board
L1
N
BK
WH
RD
RD/WH
P7-8
P7-3
P5-3P5-2
WH
The Condenser Fan Motor
Electronic
Control Board
Condenser
Fan Motor
L1 N
BK P5-2
P6-1
WH/RD
WH
