4-6
9. On the rinse aid & detergent dispenser
pump housing, unsnap the two locking
tabs of the LED cover, and raise the cover.
10. Slide the rinse aid LED out of its holder.
LED Cover
LED & Holder
Rinse Aid & Detergent
Dispenser Pump Housing
Unsnap Tabs
