4-9
REMOVING THE UPPER OR LOWER DRAWER
1. Unplug dishwasher or disconnect power.
2. Turn off the water going to the dishwasher.
3. Disconnect the drain line from the dish-
washer.
NOTE: The components that are mounted to
the bottom of the upper and lower drawers are
identical, and are mounted in the same man-
ner. The lower drawer components will be
shown.
4. Open the lower dishwasher drawer.
5. Remove the door panel from the drawer
(see page 4-4 for the procedure).
6. Press in on the tub clips on the left and right
rails, and push the rails back about 1″.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
WARNING
8. Turn the drawer over so the bottom side is
facing up.
7. Lift the drawer from the rails, and push the
rails back into the cabinet.
Press In On Clip
Push Door Rail Back
To Next Page
