— 39 —
Fig No. Part No. Part Name
Nos.
Per Hoist
Capacity
60kg 100kg 180kg 160kg 240kg
1 E2D1521 Power supply cable 3C complete set 1
2 E2D521 Power supply cable 3C 1
3 E2D537 Cable holder C 1
4 E2D524 Cable packing C8 1
5 E2D555 Machine screw with spring washer 3
6 E2D541 Cable clamp E8 1
7 E2D551 Machine screw with spring washer 2
8 E2D541 Cable clamp E8 (Single speed) 1
9 E2D542 Cable clamp E12 (Dual/Cylinder) 1
10 E2D551 Machine screw with spring washer 2
11 E2D543 Cable support L 1
12 ED552 Machine screw with spring washer 2
21 E2D1607 Push button cord 3C complete set 1
22 E2D607 Push button cord 3C 1
23 E2D537 Cable holder C 1
24 E2D524 Cable packing C8 1
25 E2D1615 Push button switch S assembly 1
26
―――
Cord chain pin 1
27
―――
Split pin 1
28 E2D640 Lock belt 3
29
―――
Fixing sleeve 1
30 E2D555 Machine screw with spring washer 3
41 E2D1607* Push button cord 6C complete set 1
42 E2D607 Push button cord 6C 1
43 E2D537 Cable holder C 1
44 E2D525 Cable packing C12 1
45 E2D1615 Push button switch D assembly 1
46
―――
Cord chain pin 1
47
―――
Split pin 1
48 E2D640 Lock belt 3
49
―――
Fixing sleeve 1
50 E2D555 Machine screw with spring washer 3
62 E3D046 Cushion rubber 2
63 E2D044 Stopper collar 1
64 E2D045 Stopper 2
65
―――
Snap ring 1
* This complete set differs depending on power voltage and/or control voltage.
