KITO ER2M User Manual

1412
Introduction
This electric hoist ER2 is designed and manufactured for the purpose to lift and lower a load within a normal
work environment. The motorized trolley MR2 and the manual trolley are designed and manufactured for the
purpose to move the lifted load laterally with the combination with the electric hoist.
Movement of a load in a 3D direction such as up/down, forward/backward and right/left is also enabled by
combining with a crane.
This Owner's Manual is intended for those operating the KITO electric hoist ER2 and maintenance engineers
(* pesonnel with expertise).
Other than this manual, Disassembly/Reassembly Manual and Parts List are also available for the maintenance
engineers. Assign the maintenance engineers and use these materials for inspection and repair. Please contact
the nearest distributor or KITO for these materials.
Introduction ............................................................................................2
Safety Precautions ................................................................................4
Chapter 1 Handling the Product ..........................................................7
Chapter 2 Inspection ..........................................................................63
Chapter 3 Troubleshooting ................................................................93
Appendix ............................................................................................119
Warranty .............................................................................................140
CE Declaration of Conformity ..........................................................143
Table of Contents
■
Disclaimer
●
KITO shall not be liable for any damage incurred thereof due to natural disaster such as fire, earth quake
and thunderbolt, conduct by third party, accident, willful conduct or negligence by customer, erroneous use
and other use exceeding the operational condition.
●
KITO shall not be liable for any incidental damage due to the use or non-use of the product such as the loss
of business profit, suspension of business and damage of the lifted load.
●
KITO shall not be liable for any damage arising from negligence of the contents in the Owner's Manual and
the use of the product exceeding the scope of its specification.
●
KITO shall not be liable for any damage arising from the malfunction due to the combination of the product
with other devices in which KITO is not concerned.
●
KITO shall be indemnified from any loss of life, bodily injury and property damage due to the use of our
product for which it has passed 10 years since its delivery.
●
KITO shall not be liable to supply the spare parts for the product for which it has passed for 15 years since
the discontinue of the product.
DECLARATION OF CONFORMITY
We, KITO Corporation,
2000 Tsuijiarai, Showa-cho,
Nakakoma-gun, Yamanashi-ken, Japan
declare under our sole responsibility that the products:
Electric chain hoist ER, model ER2
for use with or without the relevant serial trolleys in capacity range of 125 kg up to 20 tonnes
to which this declaration relates is in conformity with the following EC directives and standards.
EC directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
Harmonized standards:
EN ISO 12100-1, 12100-2:2003 Safety of machinery
EN 14492-2:2006 Power driven hoists
EN 818-7:2002 Short link chain for lifting purposes
EN ISO 13850:2006 Emergency stop
EN 60204-1:2006 Electrical equipment of machines
EN 55011:2007 Electromagnetic disturbance characteristics
EN 61000-6-2:2005 Electromagnetic compatibility
National standards:
FEM 9.511:1986 Classification of mechanisms
FEM 9.683:1995 Section of lifting and travel motors

KITO ER2M Specifications

General

Brand	KITO
Model	ER2M
Category	Chain Hoists
Language	English
