Assembling (continued)
Chapter 1 Handling the Product
■
Checking the Number of the Assembled Adjusting Spacers and Their Positions
When installing a trolley to the beam, the length of the Suspension Shaft (width between frames) must be adjusted
in accordance with the rail width. Wrong number of wrong position of Spacers may result in the drop of the electric
chain hoist. Insert the correct number of Spacers with correct ratings and for rail width at the correct position,
referring to the following table.
1
AssemblingCombination with the Manual Trolley
Capacity(t)
Parts
Name
Beam flange width (mm)
Plain
trolley
Geared
trolley
50 58 66 74 82 90 91 98 106 113 119 125 131 137 143 144
125kg
250kg
500kg
Thin spacer
Inner 2 3 4 4 1 1 2 3 3 4 1 1 1 1 2 2 3 4 4 5 1 2 2 3 3 4 0 1 1 2 1 2
Outer 7 4 10 7 5 10 10 8 5 3 9 7 5 11 9 9
Thick spacer
Inner 0 0 0 0 1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 4 4 4 4 4 4
Outer 8 8 6 6 6 4 4 4 4 4 2 2 2 0 0 0
Fixing spacer
Inner 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Outer 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1t
125kg
250kg
500kg
1t
Thin spacer
Inner 3 4 0 1 2 2 3 3 0 1 0 1 1 2 3 3 4 4 1 1 2 2 3 3 0 0 1 1 1 1
Outer 4 10 7 5 10 10 8 5 3 9 7 5 11 9 9
Thick spacer
Inner 0 0 1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 4 4 4 4 4 4
Outer 8 6 6 6 4 4 4 4 4 2 2 2 0 0 0
Fixing spacer
Inner 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Outer 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
1.6t
2t
Thin spacer
Inner 2 3 0 0 0 0 1 2 2 3 3 4 0 1 1 2 2 3 3 4 0 1 0 1
Outer 2 7 7 4 2 0 6 4 2 0 6 6
Thick spacer
Inner 0 0 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 3 3 3 3
Outer 10
8 8 8 8 8 6 6 6 6 4 4
Fixing
spacer
Inner 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Outer 0 0 0 0 0 0 0 0 0 0 0 0
2.5t
3.2t
Thin spacer
Inner 2 3 3 4 3 4 1 1 2 2 3 3 4 4 1 1 2 2 3 3 4 4 0 1
Outer 9 7 7 12 10 8 6 12 10 8 6 13
Thick spacer
Inner 2 2 2 2 2 2 3 3 3 3 3 3 3 3 4 4 4 4 4 4 4 4 5 5
Outer 8 8 8 6 6 6 6 4 4 4 4 2
Fixing
spacer
Inner 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Outer 0 0 0 0 0 0 0 0 0 0 0 0
5t
Thin spacer
Inner 1 1 2 3 3 3 0 0 1 1 2 2 3 3 3 3
Outer 10 7 6 12 10 8 6 6
Thick spacer
Inner 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1
Outer 6 6 6 4 4 4 4 4
Fixing spacer
Inner 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Outer 0 0 0 0 0 0 0 0
