Kiturami K1-28E - Dimension

14
ۣૐ ۞ইૐ઺Ҵૐ ೠҴ࢑সӏѺ ಿ૕҃৔మ
135 165
440
71
72 65
66 67 65
197
389
740
150
275
289
A
B
E
DC
3.6 Dimension
F
G
Description Diameter
A
GasInlet
3/4"PT
B
CondensateDrain
1/2"
C Central Heating Outlet
3/4"PT
D
DomesticHotWater
Outlet
1/2"PT
E
DomesticHotWater
Inlet
1/2"PT
F Central Heating Return
3/4"PT
G
SafetyReliefValveDrain
3/4"PT
