with the machine by carefully reading these operat-
ing instructions.
Use only original accessories, consumable or replace-•
ment parts. You can find replacement parts at your
Woodster dealer.
When ordering, please state our item number as well as •
the type and year of manufacture of the device.
Controls and parts, Fig 1 + 2
Handle1
Cleaver blade2
Cleaver column3
Clamping claw4
Control arm5
Handle protection6
Table bracket (front)7
Table bracket (side)8
Table locking levers9
Cleaver table10
Vent cap/Oil ller plug11
Base frame12
Wheels13
Switches and plugs14
Stroke adjustment rod15
Motor16
Hoop guards17
PV 6000
Scope of delivery
Hydraulic Log Splitter
Small parts/Accessory bag
Operating instructions
Technical data
Dimensions L/W/H
700/450/1550
Table height mm
280/570/770
Working height mm
900
Log length cm
58/77/106
Output t
6,0
Stroke cm
50
Feed speed cm/s
4.0
Return speed cm/s
12.0
Oil volume l
4
Weight kg
96
Drive
Motor V/Hz
230/50
400/50
Input power P1 W
3000 3000
Output power P2 W
2200 2200
Operating mode
S 6/40 % S 6/40 %
Motor speed 1/min
2800 2800
Motor protection
yes yes
Phase inverter
-
yes
Subject to technical modications!
