DocumentNo.:KE-4025-06                                           18/50
 SpringReturnType
11.2TypeBS-0toBS-7
TypeBSactuatorscannotbemanuallyoperatedduetothespring intheactuator.Ifamanualoperationis
required,selectTypeBSWactuators. 

11.3TypeBSW-0toBSW-7
Turningthehandwheelcounterclockwiseopensthevalveandturningthehandwheelclockwiseclosesthevalve
(Fig.15). (Specificationforairless-close)
















 To switch from manual operation of BSW-0 to BSW-7 to automated
operation,turnthehandwheelclockwiseuntilthehandwheelstopsandthe
spindleportioncompletelygetsin the springcaseandthe spring retainer
returnstotherodguideside. 


 TypeBS-0toBS-7actuatorscannotbeoperatedmanually.



Valvestem rotation
Handwheel
Handwheel
Clockwise
Fig.15
Clockwise
Counterclockwise
Counter
clockwise
