DocumentNo.:KE-4025-06                                           25/50
TypeB-0 
■Disassembly
1.Reducetheinternalpressuretotheatmosphericlevelandremovethetubing.
2.Removethehexagonalbolts〈94〉anddisassembletheactuatorfromthebracket〈93〉
3.Fitaleverhandleorawrenchonthetopoftheshaft〈3〉androtateitcounterclockwisetodrawthepiston
〈177〉towardsthehousing〈1〉.
4.Removethehexagonalbolts〈35A〉anddisassemblethecylinder〈2〉.
5.Removethepistonnut〈13〉anddisassemblethepiston〈177〉.


 Removepistonnut<13>carefully.Itistightlythreadedandfixedwithlocking
liquid.
6.Removethehexagonalbolts〈35B〉andthehousingcap〈158〉.
7.Drawthepistonrod〈103〉towardsthehousingcap.
8.Removethesnapring〈48B〉androller〈153〉,thenpulloutthepin〈17〉.
9.Removethesnapring〈48A〉andthrustbearing〈47A〉,andpushtheshaft〈3〉 downwardstoremoveit.


 Ananchorkey〈60〉isprovidedto the  shaft tofixthescotchyoke〈142〉.
Becarefulnottoloseit.
10.Removethescotchyoke〈142〉fromthehousing〈1〉.

■Assembly
1.Forreassemblyofactuators,reversethedisassemblyprocedures.


 Before fixing the piston〈177〉with the nut〈13〉, degrease the nut threads
andapplysomelockingliquid(KITZstandard:LOCTITENo.263)tothenut
threadsandthepistonrodtopreventloosing.
2.ItisrecommendedtoreplacethepistonOrings〈45A〉androdguideOrings〈45E〉becausetheycontactwith
slidingpartsrepeatedly.
3.Applysomelubricant(KITZstandard:ShellAlvaniaEP2)toOringgrooves,cylinderinternalsurfaceandall
slidingparts.
4.Applysomeliquidgasket(KITZstandard:Threebond1206E)tothecontactfacesbetweenthehousing〈1〉
andthehousingcap〈158〉,andbetweenthehousing〈1〉andthecylinder〈2〉.
5.Afterassemblyoftheactuator,checkthevalveopeningandclosingpositionswiththepositionindicator,
thenmounttheactuatortothebracket〈93〉.


