DocumentNo.:KE-4025-06                                           26/50

■PositionAdjustment
1.AccordingtotheinstructionsinChapter15,setthevalveopeningandclosingpositionscorrectlybyadjusting
thehexagonsocketheadcapscrew〈132〉.
2.SeeChapter15fordetailsofadjustment.

AssemblyDiagramofTypeB-0 








































No.  Parts No.  Parts No. Parts No. Parts No.  Parts
1 Housing 35B Bolt 45F Oring 89 Bolt 133 Nut
2 Cylinder 36 Bolt 47A Thrustbearing 92 Connector 142 Scotchyoke 
3 Shaft 39 Screw 48A Snapring 93 Bracket 145 Washer
13 Nut 45A Oring 48B Snapring  94 Bolt 153 Roller
16A Plate 45B Oring 60 Key 97 Indicator 155 Sealwasher 
16B Washer 45C Oring 67A Bearing 98 Indicatorplate  158 Housingcap 
17 Pin 45D Oring 67B Bearing 103 Pistonrod  177 Piston
35A Bolt 45E Oring 67C Bearing 132 capscrew  

Fig.17
