Kitz RDH Series User Manual

10/31
DocumentNo.:KE-4051-00


1.Precautions 



DONOTusetheproductin an environmentwherethereisflammablegasorcorrosivegas. This
productisnotanexplosion-prooftype.Thereisariskofexplosion.



 DONOTinstalltheproductinaplacewherethereisadangerofsubmergence.
 DONOTinstalltheproductinaplacesubjecttoexternalforcessuchasvibrationwhichmayaffect
the function of the product. Take appropriate measures, such as use of a vibration absorber, if
installationinsuchaplacecannotbeavoided.
 DONOTinstalltheproductinacorrosiveenvironmentwithhighhumidityandtemperature.
 DONOTinstalltheproductoutdoors.Directsunlightshallbeavoidedbyusingasunshade,etc.even
ifitisinstalledindoors.

 Ensureasufficientspacenecessaryforinstallation,maintenanceandoperation.
 Take protective measures, such as use of a heat shield plate, against radiant heat from the
peripheralequipment.
 Take appropriate measures,such asputtingaprotectivefence,if the productis installednear a
passageway.

2.Piping


 Checktheflowdirectionofunidirectionalvalves,suchasV-cutvalvesandthree-wayvalvesbefore
installation. 
 AsshowninFig.8-1,applyawrenchtothevalveendonthepipingsidewhenmountingthevalve.If
thevalveisscrewedintothepipebyapplyinga wrenchontheoppositeend,rotatingforcemay
deformthevalvebodyanddamagethevalve(Fig.8-2).





 Usesupportstandsasappropriatetoavoidexcessiveloadtothepipe.(Securelysupporttheboth
endsofthevalvewhenametallicballvalveisinstalledonplasticpipingsystems.)
 Provideafilteringdevicesuchasastrainerontheupstreamsideofthevalveifforeignobjectssuch
assandsandmetallicparticlesarecontainedinthefluid.

 Thisproductisdeliveredwiththevalveinthefullyopenposition.Uponstartoftheoperation,the
valveautomaticallyopenstothepredeterminedposition.

Fig.8−2
Fig.8-1
Yes
No
