Kitz RDH Series User Manual

23/31
DocumentNo.:KE-4051-00


2.2ManualOperation
(1)CheckthatthelowerportiontoftheAUTO/MANUALswitchisturnedon. 
Ifitnotturnedon,presstheAUTO/MANUALswitchtoturniton.
Settingvaluesin1.1arenotapplicabletothemanualoperation.





(2)Thevalveopensby0.5%bypressingtheOPENswitchonce.
WhentheOPENswitchiskeptpressed,thevalveoperatesintheopeningdirectionandautomaticallystopsat
100%.Theopeningmovementstopswhentheswitchisreleased.

(3)Thevalveclosesby0.5%bypressingtheSHUTswitchonce.
WhentheSHUTswitchiskeptpressed,thevalveoperatesintheclosingdirectionandautomaticallystopsat
0%.Theclosingmovementstopswhentheswitchisreleased

2.3PositionIndicator
Thecurrentpositionoftheactuatoroutputaxis(valve)duringautomaticormanualoperationisindicated. 
Valveopenpositionsareindicatedasfollows.
Valve PositionIndication
FullyClosed 0%
FullyOpen 100%

Thisportionisturnedon.
