Kitz RDH Series User Manual

4/31
DocumentNo.:KE-4051-00


5.Actuator-ValveAssembly























 DONOTinstalltheproductinanyexplosiveorcorrosiveenvironment.Thisproductisnotan
explosion-prooftype. 
 DONOTperformwiringnorremovetheactuatorcoverwhilethepowerison.Thereisariskof
electricshock.
 DONOTdisassembletheactuatorfromthevalvewhilethepowerison.  Itmaydamagethe
product.
 DONOTputyourfingeroranyobjectintothevalveportforvalvepositioncheck.Itmaycause
personalinjury.


 Reducethepipeinternalpressuretoatmosphericandreleasethefluidfromthepipetopreventan
explosionduetoresidualpressureorfluid.


 DONOTdisassembletheactuatorfromthevalve.Itmaycauseamalfunctionorleakage.

 Thisoperationmanualmainlycovershowtohandlethevalveactuator.RefertotheKITZcatalogfor
detailsoftheelectricproportionatecontrolvalves.
 Followtheinstructionsinthisoperationmanualforpipingandwiringofthisproduct.Otherwise,it
maycauseanaccidentorfailure. 

 Useofametallicballvalveonplasticpipingmaycauseafailureduetoexcessiveloadduringmanual
operation.
Springwasher
Hexagonbol
t
Valve
Insulator
Indicatorplate
Connector
*Atypicalstructureisshownasa
reference.Refertotheapproved
drawingfordetails.
Actuator
Fig.4
