2.Operation

See4.PartsNameinⅠConstructionandFunctionforthenameofeachswitchandconstruction.



2.1AutomaticOperation

(1)Check thattheupper sideofthe AUTO/MANUALswitchisturnedon. Ifitisnot turnedon,pressthe

AUTO/MANUALswitch.



(2)Thecontrolischangedbythesettingvalue.See1.1SettingValueforeachsettingvalue.

 Checkthenameplateoftheproductforthesignalswhichwerespecifiedatthetimeofpurchase.



*Theoperatingmovementoftheactuatordiffersdependingonthesettingoftheopen/closeoperationtime.

・Whentheopen/closeoperationtimeissetto3seconds,thecontinuousactionisperformed.

・When the open/close operation time is set between 4 seconds and 20 seconds, an inching motion is

performed.Theinchingmotionandthestoppingtimedifferdependingonthevalveload,etc.(Fig.18)



Thebelowistheexampleofaninchingmotion,threetimesofactuationandtwotimesofstopping. Theinching

motiondiffersdependingontheserviceenvironment,valveopenposition,loadappliedtothevalve,etc.





Fig.18

Thisportionoftheswitchisturnedon.

InchingMotion

Continuous

Operation

ValveOpenPosition

Specifiedvalveopenposition

Valveopenpositionatthestart

Time

Action

Stop

Action

Stop

Action
