24/31
DocumentNo.:KE-4051-00


2.4OutputofValvePosition
Thesignalisoutputfromtheterminalblock.
Outputofthevalvepositionisnotaffectedby1.1SettingValues.
Checkthenameplateoftheproductfortheoutputofthevalvepositionwhichwasspecifiedatthetimeof
purchase.
OutputSignal
Valve
Position
Indicator
4-20mA 1-5V
FullyClosed 0% 4mA 1V
FullyOpen 100% 20mA 5V

2.5ErrorDetection
(1)HuntingError
Whenacontinuousactioncontinues1.5timesthesettime,itisjudgedasinthehuntingstate.Theoperation
isstillavailablebythecontrolinputsignal.Ifhuntingoccursduetoanyunexpectedexternalfactors,itmay
shortenthelifeofthemotor.Takepreventivemeasurebyreferringto 3WiringinⅢ Installation,Piping,
Wiring.Theactuatoroperatesasfollowswhenahuntingerrorisdetected.
・ERRORlampisturnedon.
・CURRENTVALVEPOSITIONonthevalvepositionindicatorflashes.




(2)ConstraintError
Itisjudgedthatthevalveisintheconstraintstateifthevalvedoesnotreachthetargetpositionevenafter1.5
timesthesettimeelapsedafterinputtingthecommandtoopenthevalve.Whenthevalveisintheconstraint
state,alltheoperationsotherthanresettingcannotbeperformed.Performaresetoperationandrestorethe
actuatortothenormalstatereferringto3.ProtectiveFunctioninⅣOperation.
Whenaconstrainterrorisdetected,theactuatorisinthefollowingstate.
・Powersupplytothemotoriscutoff.
・Errorlampisturnedon.
・OpenCorrectorisoutputfromtheterminalblock.(30VDC/100mAorbelow）.
・【 L.O.C.】onthepositionindicatorflashes.






 Removethecauseoftheconstraintstatebeforeperformingaresetoperationtothenormal
state.Otherwise,itmaydamagetheactuatorandthevalve.

