Kitz RDH Series User Manual

26/31
DocumentNo.:KE-4051-00


(6)Protectionagainstinputtingthecontrolinputsignalwithexcessiveorinsufficientvoltage/current
・4to20mA
Whenacontrolinputsignalhigherthantheupperlimitof20mAissupplied,thecontrolinputsignaliscut
offat20mA.Pleasedonotsupply25mAorhigher. 
When3.9mAorlowerofacontrolinputsignalissupplied,thecontrolinputsignaliscutoffat3.9mA.

・1to5V
Whenacontrolinputsignalhigherthantheupperlimitof5Vissupplied,thecontrolinputsignaliscutoff
at5V.Pleasedonotsupply6.25Vorhigher. 
When0.975Vorlowerofacontrolinputsignalissupplied,thecontrolinputsignaliscutoffat3.9mA.

・2to10V
Whenacontrolinputsignalhigherthantheupperlimitof10Vissupplied,thecontrolinputsignaliscutoff
at10V.Pleasedonotsupply12.5Vorhigher. 
When1.95Vorlowerofacontrolinputsignalissupplied,thecontrolinputsignaliscutoffat1.95V.


Example:4-20mA



Fig.19
FullyOpen
FullyClosed
LowerLimit
Upperlimit
N/A
ControlInputSignal(mA)
