86
EN
2 Drill a Ø 55 or Ø 70 pipe opening at the selected position of the outlet pipe. To
allow the water to drain properly, the pipe opening on the wall should face slightly
downwards towards the outside at an angle of 5-10°.
• Pay attention to dust prevention
and take relevant safety measures
when opening the hole.
• The plastic expansion particles
are not provided and should be
bought locally.
Step 4: Alignment of the Outlet Pipe
1
The pipe can be led out in the direction of right, rear right, left or rear left.
right
rear right
rear left
left
