5
SYMBOLS ON METER
Alternating Current (AC) Direct Current (DC)
A
Amperage
V
Voltage
µA
Micro Amps
Hz
Frequency
°
F
Degrees Fahrenheit
°
C
Degrees Celsius
Audible Continuity
%
Duty-Cycle
Diode Test Low Impedance
Capacitance Resistance (Ohms)
+ Positive – Negative
COM
Common Ground
Double Insulated Class II
Warning or Caution:
To ensure safe operation and service of this meter,
follow all warnings and instructions detailed in this manual.
Risk of Electrical Shock:
I
mproper use of this meter can lead to risk of
electrical shock. Follow all warnings and instructions detailed in this manual.
Risk of Electrical Shock:
Application around and removal from
UNINSULATED HAZARDOUS LIVE conductors is permitted.
SYMBOLS ON LCD
AC
AC Measurement DC DC Measurement
Negative Reading Data Hold
Auto Ranging
MAX
Maximum Value Hold
MIN
Minimum Value Hold Low Battery
Auto Power Off Audible Continuity
Diode Test High Voltage
k
kilo (value x 10
3
)
m
mili (value x 10
-3
)
M
Mega (value x 10
6
)
n
nano (value x 10
-9
)
μ
micro (value x 10
-6
)
V
Volts
Ohms
F
Farads
A
Amps Relative Mode
LoZ
Low Impedance
%
Duty Cycle
Hz
Frequency (Hertz)
°
C
Degrees (Celsius)
°
F
Degrees (Fahrenheit)
INRUSH
Inrush Current
LPF
Low-Pass Filter
T1
T1 Temperature
T2
T2 Temperature
T-CAL
Temperature Calibration
T1-T2
Differential Temperature
AVG
Average
AC+DC
AC Voltage + DC Voltage
WARNINGS
• Use caution when working with voltages above 25V AC RMS or
60V DC. Such voltages pose a shock hazard.
• To avoid false readings that can lead to electrical shock, replace
batteries when a low battery indicator appears.
• Do not attempt to measure resistance or continuity on a live circuit.
• Always adhere to local and national safety codes. Use personal
protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.
• Do not attempt to measure voltages greater than 600V in LoZ setting.
• To avoid risk of electric shock, disconnect leads from any voltage
source before removing battery door.
• To avoid risk of electric shock, do not operate meter while battery
door is removed.
