7
FUNCTION BUTTONS
ON/OFF
To power ON the meter, rotate the Function Selector switch
2
from
the OFF setting to any measurement setting. To power OFF the meter,
rotate the Function Selector switch
2
to the OFF setting. By default,
the meter will automatically power OFF after 10 minutes of inactivity.
To deactivate the power OFF functionality press and hold the SEL
button
9
before powering ON from the OFF setting. When auto
power OFF is deactivated, the Auto Power Off icon will not be
visible in the display.
SEL (SELECT) BUTTON (FOR SECONDARY FUNCTIONS)
The SEL button
9
activates the secondary function for each
application accessible by the function selector switch
2
:
• In Voltage
V /
and Low Impedance modes, it toggles
between AC and DC measurements.
• In Temperature
mode, it toggles between
°F (Fahrenheit) and
°C (Celsius) measurements.
• In Continuity/Resistance/Capacitance/Diode-Test
mode, it
toggles through these measurements in order
.
The default function for each application is printed on the meter in
white, the secondary functions in orange. An icon on the LCD display
will indicate which function is active.
DATA HOLD
Press the Data Hold / Backlight button
6
to hold the measurement
on the display. Press again to release the display to return to live
measuring.
BACKLIGHT
Press and hold the Data Hold / Backlight button
6
for more than 2
seconds to turn ON the backlight. Repeat process to turn OFF.
RANGE
The meter defaults to auto-ranging mode . This mode
automatically determines the most appropriate measurement range
for the testing that is being conducted. To manually force the meter to
measure in a different range, use the Range button
7
.
1. Press the "RANGE" button
7
to manually select measurement
range ( is deactivated on the LCD). Repeatedly press the
"RANGE" button
7
to cycle through the available ranges, stopping
once the desired range is reached.
2. To return to auto-ranging mode, press and hold the "RANGE"
button
7
for more than one second ( is reactivated).
